152
ChipProg Device Programmers
the longest record in the column.
Tabs
Add Tab
Remove Tab
Edit Tab Name
Global Debug/ Display
Lists all the tabs present in the window.
Opens the Add New Tab to Watches Window dialog for entering a
new tab’s name. The window adds this new tab upon pressing OK .
Removes the tab selected in the Tabs list.
Opens the Edit Watch Window Tab Name dialog for editing the tab
name.
Opens the Debug Options dialog.
Options
Note. To make grids visible in the Watches window open the Configure menu , the Environment dialog,
the Fonts tab and check corresponding boxes in the Grid field.
7.3.2.2
The Add Watch Dialog
Use this dialog box to add symbol names (for example, a variable name or an expression ) to the Watches
window. The dialog contains a list of the symbol names defined in or known to the program.
Element of dialog
Name or expression to
watch:
History
Description
Enter into this box the symbol name or expression to be added. You
can specify several names and expressions either manually
(separated with semicolons) or by selecting in the list with the Ctrl key
pressed.
The list of previous names and expressions.
7.3.3
The User Window
The User window is a window that can be created by means of the built-in OpenUserWindow function
executed from the script itself. The User windows enable:
drawing graphical objects (indicators, LEDs, buttons, arrows, etc. by means of the built-in graphical
output functions;
displaying texts in the window;
User windows (see WaitWindowEvent ).
With this capability, you can organize window operations in the interactive mode. For more information,
see Script Files .
All functions working with windows (including the User window) obtain the window identifier (handle) as
a parameter. Therefore, you can have several windows of this type opened at the same time.
The User windows do not have a local menu. They only have toolbars with 16 buttons ( 0 ... F ), and each
button can be programmed to perform a certain function. Pressing a button generates the
WE_TOOLBARBUTTON event.
? 2010 Phyton, Inc. Microsystems and Development Tools
